004671381
EB2 800/3VE 800A 3p 1100V Molded Case Circuit Breaker
- ETI Code:
- 004671381
- Application:
- IEC/EN 60947-2
- Rated current:
- 800 A
- Number of poles:
- 3
- Connection type:
- FRONT
- Rated impulse withstand voltage Uimp:
- 8 kV
- Rated operational voltage (AC):
- 1,100 V
- Rated Insulation Voltage:
- 1,100 V
- Thermal Adjustment:
- yes
- Adjustable or fixed:
- adjustable
- Rated short-circuit breaking capacity at 1100V Icu/Ics:
- 18/13.5 kA
- Standards:
- IEC/EN 60947-2
- Function:
- MCCB
4 Documents
11 Logistics
Product
- Net weight of the product
- 8.5 kg
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895905578
- Transport packaging weight
- 8.5 kg
- Transport Packaging Dimensions Height
- 230 mm
- Transport Packaging Dimensions Width
- 440 mm
- Transport Packaging Dimensions Depth
- 190 mm
- Transport packaging volume
- 19.228 dm³
- Pallet quantity
- 50 pcs
- Customs tariff
- 85362090
2 ETIM
- Rated permanent current Iu
- 800 A
- Number of poles
- 3
ETIM Classification – Version 9.0
