004671379
EB2 400/3VE 400A 3p 1100V Molded Case Circuit Breaker
- ETI Code:
- 004671379
- Application:
- IEC/EN 60947-2
- Rated current:
- 400 A
- Number of poles:
- 3
- Connection type:
- FRONT
- Rated impulse withstand voltage Uimp:
- 8 kV
- Rated operational voltage (AC):
- 1,100 V
- Rated Insulation Voltage:
- 1,100 V
- Thermal Adjustment:
- yes
- Adjustable or fixed:
- adjustable
- Rated short-circuit breaking capacity at 1100V Icu/Ics:
- 12.5/6.3 kA
- Standards:
- IEC/EN 60947-2
- Function:
- MCCB
4 Documents
11 Logistics
Product
- Net weight of the product
- 4.3 kg
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895905554
- Transport packaging weight
- 4.3 kg
- Transport Packaging Dimensions Height
- 145 mm
- Transport Packaging Dimensions Width
- 265 mm
- Transport Packaging Dimensions Depth
- 180 mm
- Transport packaging volume
- 6.916 dm³
- Pallet quantity
- 96 pcs
- Customs tariff
- 85362090
13 ETIM
- Motor drive optional
- Yes
- Complete device with protection unit
- Yes
- Rated permanent current Iu
- 400 A
- Degree of protection (IP)
- IP20
- Type of control element
- Toggle
- Position of connection for main current circuit
- Front side
- Type of electrical connection of main circuit
- Screw connection
- Number of poles
- 3
- Device construction
- Complete device in housing
- Overload release current setting(Min)
- 252 A
- Rated voltage(Min)
- 1,100 V
- Rated voltage(Max)
- 1,100 V
- Overload release current setting(Max)
- 400 A
ETIM Classification – Version 9.0
