004656864
LPC-DW 30 kVAr, 440V, 50HZ Capacitor
- ETI Code:
- 004656864
- Rated DC voltage:
- 440 V
- Catalogue Group:
- LPC-DW
- Reactive power:
- 30 kVAr
- Rated AC voltage:
- 440 V
- Rated capacitance:
- 3x164.42
- Rated current:
- 39.36 A
- Connection type:
- Screw terminal
- Type description:
- Dry
14 Logistics
Product
- Net weight of the product
- 3.9 kg
- Net width
- 186.8 mm
- Net height
- 277.7 mm
- Net depth
- 186.83 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895822714
- Transport packaging weight
- 4.07 kg
- Transport Packaging Dimensions Height
- 280 mm
- Transport Packaging Dimensions Width
- 130 mm
- Transport Packaging Dimensions Depth
- 130 mm
- Transport packaging volume
- 4.732 dm³
- Pallet quantity
- 211 pcs
- Customs tariff
- 85321000
