004656794
LPC 25 kVAr, 525V, 50Hz Capacitor
- ETI Code:
- 004656794
- Rated DC voltage:
- 525 V
- Catalogue Group:
- LPC
- Reactive power:
- 25 kVAr
- Rated AC voltage:
- 525 V
- Rated capacitance:
- 3x96.2
- Rated current:
- 27.5 A
- Connection type:
- Screw terminal
- Type description:
- Dry
14 Logistics
Product
- Net weight of the product
- 2.9 kg
- Net width
- 106.7 mm
- Net height
- 322 mm
- Net depth
- 112.36 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895697053
- Transport packaging weight
- 3.03 kg
- Transport Packaging Dimensions Height
- 335 mm
- Transport Packaging Dimensions Width
- 110 mm
- Transport Packaging Dimensions Depth
- 110 mm
- Transport packaging volume
- 4.054 dm³
- Pallet quantity
- 246 pcs
- Customs tariff
- 85321000
3 ETIM
- Capacity
- 96.2 µF
- Length
- 310 mm
- Diameter
- 100 mm
ETIM Classification – Version 9.0
