004656791
LPC 12.5 kVAr, 525V, 50Hz Capacitor
- ETI Code:
- 004656791
- Rated DC voltage:
- 525 V
- Catalogue Group:
- LPC
- Reactive power:
- 12.5 kVAr
- Rated AC voltage:
- 525 V
- Rated capacitance:
- 3x48.1
- Rated current:
- 13.7 A
- Connection type:
- Screw terminal
- Type description:
- Dry
14 Logistics
Product
- Net weight of the product
- 2.2 kg
- Net width
- 106.7 mm
- Net height
- 357 mm
- Net depth
- 112.36 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895697022
- Transport packaging weight
- 2.31 kg
- Transport Packaging Dimensions Height
- 260 mm
- Transport Packaging Dimensions Width
- 110 mm
- Transport Packaging Dimensions Depth
- 110 mm
- Transport packaging volume
- 3.146 dm³
- Pallet quantity
- 317 pcs
- Customs tariff
- 85321000
3 ETIM
- Capacity
- 48.1 µF
- Length
- 225 mm
- Diameter
- 100 mm
ETIM Classification – Version 9.0
