004656760
LPC 10 kVAr, 440V, 50Hz Capacitor
- ETI Code:
- 004656760
- Rated DC voltage:
- 440 V
- Catalogue Group:
- LPC
- Reactive power:
- 10 kVAr
- Rated AC voltage:
- 440 V
- Rated capacitance:
- 3x54.8
- Rated current:
- 13.1 A
- Connection type:
- Screw terminal
- Type description:
- Dry
14 Logistics
Product
- Net weight of the product
- 1.6 kg
- Net width
- 91.6 mm
- Net height
- 272 mm
- Net depth
- 104.81 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895696780
- Transport packaging weight
- 1.69 kg
- Transport Packaging Dimensions Height
- 260 mm
- Transport Packaging Dimensions Width
- 95 mm
- Transport Packaging Dimensions Depth
- 95 mm
- Transport packaging volume
- 2.346 dm³
- Pallet quantity
- 426 pcs
- Customs tariff
- 85321000
3 ETIM
- Capacity
- 54.8 µF
- Length
- 225 mm
- Diameter
- 85 mm
ETIM Classification – Version 9.0
2 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
19 Tags
004656760CapacitorLPC 10 kVAr, 440V, 50HzCPThree-phase capacitorsThree phase low voltage power capacitors LPCScrew terminalScrew terminal440VInternationalReactive power compensation devices CPThree phase capacitorRated capacitance: 3x54.8 μFConnection type: Screw terminalType description: DryReactive power: 10 kVAr/10 kVArRated AC voltage: 440 V/440 VRated current: 13.1 A/13.1 ACapacitor
