001343901
AW-R 5 SET Washer
- ETI Code:
- 001343901
- To use with:
- SOLID GSX system
- Product group accessories:
- Screws, nuts and washers
- Catalogue Group:
- SOLID GSX Accessories
- Function:
- Accessories
- Function accessories:
- Washer
3 Documents
7 Logistics
Product
- Net weight of the product
- 0.004 kg
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 5902047606915
- Basic packaging weight
- 0.004 kg
- Basic packaging volume
- 0.024 m³
Transport Packaging
- Customs tariff
- 85389099
7 ETIM
- Surface protection
- Galvanic/electrolytic zinc plated
- Inner diameter
- 5.4 mm
- Material quality
- C45 (steel)
- Thickness
- 1 mm
- Outer diameter
- 10 mm
- Material
- Steel
- Suitable for bolt size (metric)
- 5
ETIM Classification – Version 9.0
